| Video/Audio Input |
|---|
| Audio Input:1-ch |
| Video Compression:H.265+/H.265/H.264+/H.264 |
| Analog and HD-TVI video input:8-ch,BNC interface (1.0Vp-p, 75 Ω)connection |
| Video Input Interface:BNC (1.0 Vp-p, 75Ω) |
| Audio Compression:G.711u |
| Audio Input Interface:RCA (2.0 Vp-p, 1 kΩ) |
| Two-way Audio:1-ch, RCA (2.0 Vp-p, 1 KΩ), (using the 1st channel of audio input) |
| Video/Audio Output |
| CVBS Output:1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704x576,NTSC:704x480 |
| HDMI/VGA Output:1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
| Recording resolution:When 1080p Lite mode not enabled: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode enabled: 1080p lite/720p lite/VGA/WD1/4CIF/CIF |
| |
| Video Bit Rate:32 Kbps-6 Mbps |
| Stream Type:Video/Video&Audio |
| Two-way Audio:1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input) |
| Audio Output:1-ch RCA(Linear, 1kΩ) |
| Audio Bit Rate:64kbps |
| Dual Stream:Support |
| Playback Resolution:3 MP/1080p/720p/VGA/WD1/4CIF/CIF |
| Synchronous Playback:8-ch |
| Network management |
| Remote connections:128 |
| Network protocols:TCP/IP, PPPoE, DHCP, Hik-connect Cloud P2P,DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP?, HTTPS,ONVIF |
| Hard Disk Driver |
| Interface Type:2 SATA Interfaces |
| Capacity:Up to 6 TB capacity for each disk |
| External Interface |
| Network Interface:1; 10M / 100M self-adaptive Ethernet interface |
| USB Interface:2 USB 2.0 Interfaces |
| Serial Interface:1; standard RS-485 serial interface, half-duplex |
| General |
| Power Supply:12 VDC |
| Consumption:≤ 7.5W(without hard disks) |
| Working Temperature:-10 oC to +55 oC (14 oF to 131 oF) |
| Working Humidity:10% to 90% |
| Dimensions:380 × 320 × 48 mm (15.0 × 12.6 × 1.9 inch) |
| Weight:≤ 1.78 kg (3.9 lb) |
top of page
Hikvision 8 Channel Turbo HD DVR
