Hikvision 4 Door Control Panel

N150 000.00

Pre-order

Out of stock, available for pre-order

Product Details

Brand: Hikvision

Hikvision 4 Door Control Panel @ N103,000. This amazing Control panel has a high speed 32-bit processor, with in built TCP/IP communication and stores up to 300,000 logs. Also available at Sterling Magna Technologies office at Ajah, off Lekki Epe Expressway, Lagos state, Nigeria. This product can be shipped to any location in Lagos, Abuja, Port Harcourt, Kano and across Nigeria.

System Parameters
Storage:		cards information: 100,000 (200,000 expandable) access control events : 300,000 (600,000 expandable)
Capacity:		16M
Processor:		32-bit

Device Interfaces
Accessible Card Reader:		4 Card Readers (RS485 Interface) and 4 Card Readers (Wiegand Interface) Connectable
Uplink Communication Interface:		TCP/IP Network Interface and RS-485 Interface
Downlink Communication Interface:		RS-485 and Wiegand (W26/W34)
Output Interface:		Lock Relay×2, Alarm Relay×4
Input Interface:		Alarm Input×4,Door Sensor×2,Exit Button×2,Case Input×4,Tamper Alarm×1

General
Working Voltage:		DC 12V/1A
Power Consumption:		≤4W(Without Load); ≤100W(with Load)
LED Indicator:		Power Supply Status, Communication Status, Working Status
Certification:		CE, FCC
Working Humidity:		10% to 90% (Non-Condensing)
Working Temperature :		-20°C to +65°C (-4°F to +149°F)
Dimensions (L×W×H):		370mm x 345mm x 90 mm (14.6” x 13.6” x 3.5")
